Parameter Wert
Total size of buffer memory: 655,360 bytes
Data needed for one "TestBook" entry:
24 bytes
Max. number of "TestBook" entries:
655,360 bytes / 24 bytes = 27,306 entries
for Capacity of the buffer memory one test per week
and device:
655,360 bytes / (24 bytes * 128 devices) = 213 weeks
≥ 4 years
5.1.5. Main menu
The basic system settings can be adapted, the emergency units assigned and the tests configured in the Main
menu.
The following functions can be accessed using the buttons on the "Main menu":
Button Function
Test times Used to specify a time schedule for the function and duration test
Commissioning test Used to start the function and duration test manually
Identification tool Used to convert the identification flashing into the emergency unit address
I NOTICE
"TestBook" entries are written to the buffer memory. If the memory is full, the oldest will be deleted "Test Book" to
make room for new entries.
The following calculation shows how many entries can be saved before this is the case.
are also the time then, the If durations tests and negative communication tests performed, decreases. But even
size of the buffer memory is sufficient for more than 2 years.
If the feature "cyclic communication test" is used the test-book may be overwritten!
