Miscellaneous I/O Card Output Connections
Commander D25 Fixed Socket
Pins
Upper Connector
Description
1
Ground
2/14
Output 1
3/15
Output 2
4/16
Output 3
5/17
Output 4
6/18
Output 5
7/19
Output 6
8/20
Output 7
9/21
Output 8
10/22
Output 9
11/23
Output 10
12/24
Output 11
13/25
Output 12
Commander D25 Fixed Socket
Pins
Lower Connector
Description
1
Ground
2/14
Output 13
3/15
Output 14
4/16
Output 15
5/17
Output 16
6/18
Output 17
7/19
Output 18
8/20
Output 19
9/21
Output 20
10/22
Output 21
11/23
Output 22
12/24
Output 23
13/25
Output 24
Typical external circuitry for the logic outputs is given on Page 28.
Miscellaneous I/O Card RS422/Monitoring Connections
Commander D9 Fixed Socket
Pin
Description
1
Ground
2
RS422 Out-
3
RS422 In-
4
Audio Monitor Out-
5
Not Used
6
RS422 Out+ OR RS232 Out
7
RS422 In+ OR RS232 In
8
Audio Monitor Out+
9
Not Used
Further information is available in the 500-10 Technical Manual, which is available on
request from Trilogy Communications.
