Commander Installation Guide
Page 48 of 81 Trilogy Communications Limited
Issue 9.1
5.10 500-33-00 / 500-45-00 / 500-46-00 RANGE
Although offering differing types and numbers of switches and displays, these panels share
the same electronics and connectivity.
• 500-33-00 32 way lever key
• 500-45-00 8 way push button
• 500-46-00 10 button, LC key.
5.10.1 SPECIFICATION
Dimensions
o 500-33-00
485mm wide x 88.9mm high x 80mm deep (approx. including
PSU and mating connectors).
19” x 2RU rack mounting
o 500-45-00 / 500-46-00
485mm wide x 44.5mm high x 80mm deep (approx. including
PSU and mating connectors).
19” x 1RU rack mounting
Mains Input
90 – 250 V ac, 50-60Hz
Current Consumption
150mA @ 90V, 50mA @ 250V
5.10.2 CONNECTIONS
Matrix – RJ-45 fixed socket on panel
RJ-45
Pin
Function
1
Panel Data out +
Pair
1
2
Panel Data out -
3
Panel Data In +
Pair
2
6
Panel Data In -
5
Panel Audio out +
Pair
3
4
Panel Audio out -
7
Panel Audio in +
Pair
4
8
Panel Audio in -
Cable Screen
Headset - 5 Pin XLR Fixed Socket (front
panel)
Pin
Function
1
Mic IN (Screen)
2
Mic IN
3
Headset Gnd
4
Headset Out
5
Headset Out
Foot Switch - D9 Fixed Socket
Pin
Function
1
Foot Switch Input
2
No Connection
3
Chassis Ground
4
Reserved
5
Reserved
6
Ground
7
Reserved
8
Reserved
9
Reserved
