8.4 MATRIX PORTS – D9
The same connector pin-out applies to ports used for panels or externals. External (4-wire)
connections will not use the data pairs. Cable is quad twisted 100Ω pair, with overall screen.
STP or FTP cables should be used for all installed cables. See Specification for maximum
cable length. We suggest a CAT 5 type cable, from a recognised supplier such as Beldon.
Matrix
D9 Fixed Socket
Pin
Description
Notes
1
Cable screen
2
Pair with pin 6, Data - from panel.
Only applies to ports used for panels
3
Pair with pin 7, Data – to panel.
Only applies to ports used for panels
4
Pair with pin 8, Audio - from panel.
5
Pair with pin 9, Audio - to panel
6
Pair with pin 2, Data + from panel.
Only applies to ports used for panels
7
Pair with pin 3, Data + to panel.
Only applies to ports used for panels
8
Pair with pin 4, Audio + from panel
9
Pair with pin 5, Audio + to panel
Thus, the panel cables should be wired “pin to pin” with the pairs as follows.
Pair
D9 Pin (+,-)
Function
1
6,2
Data from panel to matrix
2
7,3
Data to panel from matrix
3
8,4
Audio from panel to matrix
4
9,5
Audio to panel from matrix
1
Cable Screen
