Trilogy Communications Commander - Connecting Via Structured Cabling

Commander Installation Guide
Page 74 of 81 Trilogy Communications Limited
Issue 9.1
8.5.4.4 500-3x-3x Series Expansion panel interconnection cables
Type A (max. length 10 metre)
D9 Free Plug -
Pin
Function
Function
D9 Free Plug -
Pin
4
Transputer
Data out +
Pair 1
Transputer
Data in +
4
8
Transputer
Data out -
Transputer
Data in -
8
5
Transputer
Data In +
Pair 2
Transputer
Data out +
5
9
Transputer
Data In -
Transputer
Data out -
9
3
Ground
Ground
3
Type B (max length 10 metres)
D9 Free Plug -
Pin
Function
Function
D9 Free Plug -
Pin
4
Transputer
Data out +
Pair 1
Transputer
Data in +
5
8
Transputer
Data out -
Transputer
Data in -
9
5
Transputer
Data In +
Pair 2
Transputer
Data out +
4
9
Transputer
Data In -
Transputer
Data out -
8
3
Ground
Ground
3
8.5.5 CONNECTING VIA STRUCTURED CABLING
All control panel types may be connected to the matrix by Category 5 structured cabling
systems. Suitable adaptors are available from most electronic component distributors. The
RS part numbers are listed below.
Panel Connection: RJ45 to D9 socket. RS 818-700
Matrix Connection: RJ45 to D9 plug. RS 818-693
As supplied, these adaptors require the pins to be inserted into the D type housing. Use the
following table as a guide. The colour codes may not be correct for other brands.
D9 pin
RJ 45 pin
Colour (see above)
1
No connection
No connection
2
2
Yellow
3
6
Brown
4
4
Red
5
8
Blue
6
1
Black
7
3
Orange
8
5
Green
9
7
Grey
