5.5.4 500-3X-5X SERIES DIP SWITCH SETTINGS
Within the panel a series of DIP switches determine the correct panel type. These are
factory set and are included for reference in Appendix 1.
A further set of DIP switches are user accessible at the rear of the panel and control the
action of the front panel CUT switch. The factory default is shown in the table below. Switch
position 4 is not used.
Cut Switch Action
DIP 1
DIP 2
DIP 3
No action
OFF
OFF
OFF
Changeover to HSet MIC (default)
ON
OFF
OFF
LS cut
OFF
ON
OFF
Changeover to HSet MIC and LS cut
ON
ON
OFF
MIC cut
OFF
OFF
ON
Changeover to HSet MIC and MIC cut
ON
OFF
ON
LS cut and MIC cut
OFF
ON
ON
Everything
ON
ON
ON
