9.5 MISCELLANEOUS I/O CARD
Number of physical Inputs
28, grounding contact
Number of physical Outputs
24, earth-free opto-isolated mosfet
Loopback I/O
Outputs 29-40 internally loped back to inputs
29 to 40.
Tone Generator
3 tones generated, 315Hz, 1kHz, 1.9kHz
“Blip” Generator
3 off 450ms blips generated, triggered from
outputs 25, 26 and 27 respectively
Input Logic Monitoring
4 LEDs with card edge selector to allow any
state of inputs in blocks of 4 to be monitored
Output Logic Monitoring
4 LEDs with card edge selector to allow any
state of outputs in blocks of 4 to be
monitored
Input Audio Source Monitoring
Any 1 of 384 system audio sources
monitored by card edge bar-
graph display,
card edge 3.
5mm headphone socket, and
rear connector output.
Remote Control
Selectable RS232/422 and baud rate.
Remote control of logic inputs, and output
dump when logic outputs made - please ask
Trilogy Communications for further details.
9.6 P.C.
Type
Any IBM PC or compatible computer running
Windows 2000 or later
We suggest a
Pentium 1
GHz (or better) with a minimum
512MB of RAM.
