Triton Digital Mixer Shower Installation Guide

11
4
3
6
1
2
7
8
1. Digital Processor Unit Cover
2. Digital Processor Unit Fixing positions
3. Digital Processor Unit AC Power Lead
4. 15mm push fit connectors with Isolating valves
5. 15mm push fit connectors
6. Digital Processor Unit Inlets (HOT & COLD)
7. Digital Processor Unit Outlets*
8. Digital Processor Unit Data Cable connector
5
9. Digital Controller
10. Controller Fixing Bracket
11. 10m Data Cable
*(The number of outlets will vary depending on the configuration of the Digital Mixer
Shower purchased).
