20
Mixer processor
installation
Before any electrical work is attempted, ensure the electricity supply
is isolated at the mains switch.
Electrical installation may only be carried out by a qualied person.
Electrical connections
Connect the Digital Processor Unit AC Power Lead to a double pole 3Amp switched
fused spur (Fig.12), incorporated in the wiring circuit, in accordance with current wiring
regulations.
The 3Amp fused spur MUST be located in a dry, easily accessible position. Access to
the fused spur is required for servicing and maintenance
Neutral cable marked N Blue
Live cable marked L Brown
DO NOT switch on the electricity supply until all the pipe connections have been tested for
leaks and the commissioning procedure has been followed.
