MAINTENANCE AND ADJUSTMENT
119
If a problem is detected or any doubt
exists, the forks must be inspected by
a competent person with the specialist
knowledge and technical understanding
of motorcycles, such as an authorized
Triumph dealer.
Rear Suspension
Rear Suspension Settings
The motorcycle is delivered from the
factory with all the suspension settings
set at the Standard setting.
Refer to the following table or
for further information contact a
competent person with the specialist
knowledge and technical understanding
of motorcycles, such as an authorized
Triumph dealer.
Rear Suspension Settings
Loading Spring Preload
1
Solo Riding 1
Rider and Passenger 10
1
Position 1 is minimum (fully clockwise) and
position 10 is maximum (fully counterclockwise).
The details shown in the table are only
a guide. Setting requirements may vary
for rider and passenger weight and
personal preferences.
Rear Suspension Spring Preload
Adjustment
The spring preload adjuster is located at
the bottom of the rear suspension unit.
Rear adjuster settings are counted from
one, with position one being with the
adjuster turned fully clockwise. Position
one gives the minimum amount of
spring preload. There are ten adjuster
positions in total. Position ten gives the
maximum amount of spring preload.
▼ Insert the adjustment tool (supplied
with the motorcycle) into the slots
of the spring preload adjuster ring.
