Triumph Speed 400 - Seat - Removal

GENERAL INFORMATION
57
The seat lock is located on the left hand
side of the motorcycle, on the frame
below the seat.
cldz
1
1. Seat lock (Scrambler 400 X shown)
The seat can be removed to gain access
to the battery and fuse box.
Seat - Removal
WARNING
Make sure the motorcycle is stabilized
and adequately supported.
Do not support the motorcycle on
any ancillary component, the exhaust
system or any other non structural
parts of the motorcycle frame.
A correctly supported motorcycle will
help prevent it from falling.
An unstable motorcycle may fall
resulting in motorcycle damage,
serious injury or death.
NOTICE
To prevent damage to the seats or
seat covers, care must be taken not to
drop the seats.
Do not lean the seats against the
motorcycle or any surface which may
damage the seats or seat covers.
Instead, place the seats, with the seat
cover facing upwards, on a clean, flat
surface which is covered with a soft
cloth.
Do not place any item on the seats
which may cause damage or staining
to the seat covers.
Speed 400
Seat
▼ Insert the ignition key into the seat
lock.
▼ Turn the ignition key clockwise while
pressing down on the rear of the
seat. This will release the seat from
its lock.
▼ Lift the seat up from the back
and slide rearwards for complete
removal from the motorcycle.
cleq
2
1
1. Seat lock
2. Seat
