GENERAL INFORMATION
59
Speed 400
Seat
▼ Engage the hook at the front of the
seat under the bracket at the rear
of the fuel tank.
cleo
2
1
1. Hook
2. Bracket
▼ Align the locating peg into the lock
and press down engaging the seat
lock.
NOTICE
An audible click can be heard when
the seat is fully engaged in its lock.
clep
2
1
1. Locating peg
2. Lock
WARNING
To prevent detachment of the seat
during riding, after installation always
grasp the seat and pull firmly upwards.
If the seat is not correctly secured in
the lock, it will detach from the lock.
A loose or detached seat may lead to
loss of motorcycle control which could
result in serious injury or death.
▼ Grasp the seat and pull firmly
upwards to make sure it is securely
retained.
Scrambler 400 X
Rider’s Seat
▼ Engage the hook at the front of the
seat under the bracket at the rear
of the fuel tank.
cldx
2
1
1. Hook
2. Bracket
▼ Lower the rear of seat and align the
holes for the fasteners.
