tronical Tune - Function Overview

WWW.TRONICAL-COMPONENTS.COM
21
STRING UP AND DOWN MODE / CUSTOM TUNING /
REFERENCE TUNING / FIRMWARE VERSION / BATTERY LEVEL
FUNCTION OVERVIEW
FUNCTION MENU
BAT
e B G D A E
MENU
BAT
e B G D A
MENU
BAT
e B G D A
MENU
PUSH “ON“ button. The system activates with the last completed tuning in
MULTISTRING MODE.
PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED is OFF.
TO ENTER FUNCTION MENU:
PRESS AND HOLD THE “UP“ button until MENU LED lights up WHITE.
PRESS “LEFT/RIGHT“ to navigate through the FUNCTION MENU (E, A, D, G, B).
PRESS “ENTER“ to confirm or PRESS “BACK“ for TUNING SELECTION MODE.
FUNCTION MENU OVERVIEW
STRING UP AND DOWN MODE PG. 11
CUSTOM TUNING MODE PG. 2021
REFERENCE TUNING PG. 22
FIRMWARE VERSION PG 23
BATTERY LEVEL PG. 24
ON/BACK
BACK
LEFT / RIGHT
UP
E
E
ENTER
FUNCTION MENU
E
A
D
G
B
