tronical Tune - Configuration Menu Overview; Accessing Configuration Menu; Configuration Menu Options

WWW.TRONICAL-COMPONENTS.COM
27
ACCURACY LEVEL / ROBOHEAD DELAY /
RESET / ROBOHEAD SPEED / INTERFERENCE LEVEL
BAT
e B G D A E
MENU
BAT
e B G D A
MENU
BAT
e B G D A
MENU
PUSH “ON“ button. The system comes up with the last
completed tuning in MULTISTRING MODE.
PUSH “BACK“ button to enter TUNING SELECTION MODE.
MENU LED is OFF.
TO ENTER CONFIGURATION MENU:
PRESS AND HOLD THE “DOWN“button until MENU LED and “E“ TURNS LIGHT
BLUE.
PRESS “LEFT/RIGHT“ BUTTON TO SELECT THE DESIRED FUNCTION BELOW.
BACK
LEFT / RIGHT
E
E
ENTER
FUNCTION MENU
OVERVIEW
CONFIGURATION MENU
ENTER
DOWN
LEFT / RIGHT
ON/BACK
CONFIGURATION MENU OVERVIEW
ACCURACY LEVEL PG. 29
ROBOHEAD DELAY PG. 30
RESET PG. 31
ROBOHEAD SPEED PG. 32
INTERFERENCE LEVEL PG. 33
A
D
G
B
e
