tronical Tune - Function Menu: Reference Tuning; Setting a Reference Tuning; Using the Reference String

WWW.TRONICAL-COMPONENTS.COM
24
BAT
e B G D A E
MENU
BAT
e B G D A
MENU
SEQUENCE
1 TUNE THE GUITAR TO THE DESIRED TUNING PRESET.
2 CHANGE THE PITCH OF ONE STRING REFERENCE STRING
BY MANUALLY TURNING THE KEY.
3 ENTER AND EXECUTE REFERENCE MODE
TO ENTER REFERENCE TUNING MODE
:
PUSH “ON“ button. The system activates with the last completed tuning in
MULTISTRING MODE.
PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED is OFF.
PRESS AND HOLD THE “UP“ button until MENU LED lights up WHITE.
PRESS “LEFT/RIGHT“ button to SELECT WHITE “D“LED.
PRESS “ENTER“ for REFERENCE TUNING MODE. The MENU LED switches OFF
ELED FLASHES RED.
PRESS “LEFT/RIGHT“ button to SELECT THE REFERENCE STRING.
PLUCK YOUR REFERENCE STRING measurement begins indicated by
quick FLASHING YELLOW LED of respective string. Upon completion,
the respective led lights up GREEN and all others are shining RED.
STRUM ALL STRINGS MULTISTRING MODE.
The system will tune your guitar to the selected tuning preset in relation
to the measured reference pitch.
E
D
ENTER
BAT
e B G D A E
MENU
MOVE TO RETUNED STRING
THE LATEST COMPLETED REFERENCE TUNING IS AVAILABLE ON
STARTUP UNTIL YOU COMPLETE ANY OTHER TUNING.
SHOULD YOU WISH TO STORE YOUR REFERENCE TUNING REFER TO
“CUSTOM TUNING“ PAGE 2324.
REFERENCE TUNING
D
FUNCTION MENU
i
