INSTALL THE SYSTEM TO THE GUITAR
GETTING STARTED
NOTE: DO NOT USE ANY TOOLS TO FIX THE LOCK NUT
AND DO NOT OVER TIGHTEN AS YOU MAY. USE A 1 CENT COIN TO TIGHTEN
THE LOCKNUT, OTHERWISE YOU MAY DAMAGE THE GEAR WHEELS!!
USE ONLY SUPPLIED WRENCH OR TORQUE WRENCH TO
TIGHTEN THE HEX NUTS MAX. 1NM TORQUE
IT IS RECOMMENDED TO USE A CONTACT CLEANING SOLUTION BEFORE INSTALLING
THE ROBOHEADS TO THE PCB BOARD AND TO ALSO NOT OVER TIGHTEN THE HEX NUTS
BEFORE ENSURING ALL CONTACTS ARE MAKING A GOOD CONNECTION.
USE CAUTION WHEN INSTALLING BATTERY AND ENSURE YOU PAY ATTENTION TO THE
SLOTTED DESIGN TO GUARANTEE PROPER ORIENTATION!!!
