HOW TO USE THE STRING SHAFT WITH
SURFACE LOCKING MECHANISM
GETTING STARTED
LOCK NUT: YOU NEED THE LOCK NUT TO TIGHTEN THE STRING.
STRING SHAFT: THE STRING SHAFT WINDS THE STRING.
STRING RECESS: THE STRING RECESS GUIDES THE STRING.
HEX NUT: USE THE WRENCH WHICH COMES WITH THE SET TO
TIGHTEN THE HEX NUTS OF THE ROBOHEADS.
LOCK NUT
STRING RECESS
STRING SHAFT
HEX NUT
1
1
2
3
4
3
4
3
USE ONLY SUPPLIED WRENCH OR TORQUE WRENCH TO
TIGHTEN THE HEX NUTS MAX. 1NM TORQUE
NOTE: DO NOT USE ANY TOOLS TO FIX THE LOCK NUT
AND DO NOT OVER TIGHTEN AS YOU MAY. USE A 1 CENT COIN TO TIGHTEN
THE LOCKNUT, OTHERWISE YOU MAY DAMAGE THE GEAR WHEELS!!
