tronical Tune - Firmware Version

WWW.TRONICAL-COMPONENTS.COM
25
BAT
e B G D A E
MENU
PUSH “ON“ button. The system activates with the last completed tuning in
MULTISTRING MODE.
PUSH “BACK“ button to enter TUNING SELECTION MODE. MENU LED IS OFF.
TO ENTER FUNCTION MENU:
PRESS AND HOLD “UP“ until MENU LED lights up WHITE.
PRESS “LEFT/RIGHT“ button to SELECT WHITE “G“LED and PRESS “ENTER“.
LEDS START FLASHING THREE TIMES, ONE TIME FOR EACH OF THE THREE
FIRMWARE VERSION DIGITS. THE FIRST DIGIT NUMBER IS GREEN, THE
SECOND BLUE AND THIRD RED. EACH COLOR SYMBOLIZES VALUES FROM
16 ACCORDING TO THE DIGITS.
G
BAT
MENU
EADGBe
BAT
MENU
EADGBe
BAT
MENU
EADGBe
ENTER
EXAMPLE: LEDS FLASH THREE TIMES
FLASH: 1 FLASH: 2 FLASH: 3
1 6
0
VERSION:
ZERO IS SYMBOLIZED IF ALL LEDS ARE WHITE.
FIRMWARE VERSION
G
FUNCTION MENU
LEFT / RIGHT
UP
i
