Safety
2.8.3 Reflection through materials
Warning
Danger from laser beam.
Invisible laser radiation of reflecting materials can cause serious injury or material damage.
– Only material according to the intended use of the machine may be used.
– Do not use material with high reflecting surfaces such as aluminum, chromium, precious
metals, metal foils, stainless steel, brass, copper and titanium.
– Take special care with surfaces formed convex and concave.
– Do not leave or put objects on the work surface/working area.
Laser beam reflection
The reflecting law is valid for the reflection of the laser radiation: Angle of incidence = failure corner
No. Description
1 Directed reflection: Reflected ray on smooth surface.
2 Directed reflection: Reflected ray on sloping surface.
3 Diffuse reflection: Reflected ray on rough surface.
4 Directed reflection: Horizontally reflected ray on smooth surface.
27
