Machine overview
4.2 Front door
Loading and unloading of heavy and bulky parts or replacement
of the table is very comfortable thanks to the front door that can
be opened to up to 180°.
Notice
The door is interlocked, therefore it must be closed
before any laser operation is possible.
4.3 Tables (multifunctional table concept)
Multifunctional base frame
The multifunctional base frame is bolted to the mounting
frame, which is attached to the Z-axis.
Notice
All table variants rest on the base frame. With exception of the ferromagnetic engraving table
which may also be placed directly on the mounting frame if there is no base frame present.
Ferromagnetic engraving table
The ferromagnetic construction allows mounting thin
materials such as paper, films or foils with magnets to
ensure an even and flat surface. An even working area is
essential for achieving optimal results for laser engraving
and marking applications.
41
