Operation
7.5 Lense placement
1. Loosen lens by turning the clamping ring inwards.
2. Remove lens.
3. Check the lens for damage.
4. If necessary, clean both sides of the lens with cleaning liquid and
cleaning tissue.
5. Insert the lens with the lettering facing up, either above or below the
clamping ring depending on the lens type.
6. Fixate the lens with the clamping ring.
The following lenses must be inserted below the clamping ring:
1.5''
2.0''
Notice
All other available lenses must be inserted above the clamping ring.
67
