Technical Data
3 Technical Data
The technical data sheet can be found in the appendix of this manual.
3.1 Dimensions and weight
Description Dimension
A Length 1221 mm (48 inch)
B Width 830 mm (32.67 inch) / 790* mm (32.8 inch)*
C Height, closed with base frame 1055 mm (41.55 inch)
D Height, open 1750 mm (68.89 inch)
* Without exhaust hose connectors on the back and with the top lid open.
Weight (depends on the machine type): 235 bis 250 kg (518 to 551 lbs)
31
