Operation
Image Button Description
Working table control button
Z
•
Press one of these buttons to manually move the working
table up or down (travel distance in Z-direction).
•
Press the Shift-button together with the Up-button. The
activation of the automatic focusing starts and the working
table is moving automatically upwards.
•
Press the Shift-button together with the Down-button. The
working table is moving automatically downwards to the
corresponding end position.
By simultaneous pressing of the Up-button + Down-button, the
activation of the automatic focusing starts and the working table
is moving automatically upwards.
Press any button in X-, Y-, or Z-direction to stop the
automatically movement.
Activation of the automatic focusing:
The laser beam gets automatically focused on the work piece
(depends on the selected lens). When there is no work piece
on the working area, the focus is on the table or rather on the
tabletop.
Sonar Technology™ (option):
Focusing on the material which is below the sensor.
Caution
If there is no material on the cutting table, it could
lead to a collision of the laser head ("head crash").
Light barrier:
Focusing on the material which is close to the sensor.
For further information, see chapter "focusing" in this
manual.
Stop-button
•
Press this button to stop the current working process.
Start/Pause/Repeat-button Start:
•
Press this button to start a job. The job has to be on the
plate in JobControl®.
Pause:
•
Press this button to pause the job (LED On) which is
currently being processed. Press this button again to
continue the job (LED Off).
Repeat:
•
Press this button after a job was finished to repeat the
actual job.
