CHAPTER 2: ASSEMBLY INSTRUCTIONS
BIKE ASSEMBLY STEPS (continued):
Step 13: Pedals:
Align the Left Pedal with the Left Crank and
the Right Pedal with the Right Crank; pedals
should be clearly labeled on the Pedal Strap
b) Secure each pedal to the appropriate crank
using the provided wrench
NOTE: The left pedal is reverse-threaded (turn
counter-clockwise to tighten)
a) Insert the cup holders into the storage tray as
shown.
Step 14: Unit Leveling (if necessary):
a) Turn feet (4x, located on the front and rear
stabilizer) to adjust the levelness of the unit.
Truefitness.com / 800.426.6570 / 636.272.7100 20
