CHAPTER 4B: ESCALATE
15
OPERATION
ADVANCED CONSOLE FUNCTIONS (continued):
Setup Menu - Facility Images:
The Escalate
15
console supports customizable facility images to help promote specials, events or endorse a brand. In order
to be uploaded to the console, images will need to be placed on a USB drive in a folder named “facility” (case sensitive).
Importing Facility Images:
• Select Facility Images (A) and press Enter (B).
• Insert the USB drive that contains the images into the console’s USB port.
• Verify the images in the preview window (C)
• Select Save (D) using the Up/Down Selection Buttons (E) and press Enter (B) to save the images to the console.
* Facility images can be deleted by selecting the Clear (F) and pressing Enter (B).
Once loaded correctly, the facility Images will be displayed in the Facility Workout Data Screen (as shown below).
Truefitness.com / 800.426.6570 / 636.272.7100 82
