TSC Alpha-40L RFID User Manual

2
1.1 Product Specification
Item
Alpha-40L(R)
Resolution
203 dpi, 8dots/mm
Printing method
Direct thermal
Max. print speed
Up to 5 ips
Max. print width
104 mm (4.09”)
Max. print length
2,794 mm (110”)
Enclosure
Plastic with rubber over molded
Physical dimension (W x H x D)
160 mm x 191mm x 79 mm (6.30" x 7.52" x 3.11")
Weight (including battery)
1.025 g (2.26 lbs)
Drop specification
1.8 m (6 ft), with IP54 case can be 2.5 m (8.2 ft)
IP rating
IP54 (w/o case, paper path is excluded)
Label roll capacity
67 mm OD
Processor
32-bit RISC CPU
Memory
◼ Standard: 128 MB SDRAM, 128 MB Flash, microSD card reader for Flash memory expansion,
up to 32 GB
◼ Factory Option: 256 MB SDRAM, 512 MB Flash
Power
7.4V DC, 6,200 mAh Li-ion rechargeable smart battery
Interface
Either one selected
◼ Type C USB 2.0 + MFi Bluetooth 5.0 + Passive NFC tag
◼ Type C USB 2.0 + 802.11 a/b/g/n/ac Wi-Fi with Bluetooth 4.2 + Passive NFC tag
＊
Type C is for communication only.
Operation button
7 buttons (Power, Feed/Enter, Menu, Navigation keys)
User interface
◼ 2 LED indicators (battery charging status, printer status)
◼ 2.3” Color LCD display, 320 x 240 pixels
Sensors
◼ Reflective sensor
◼ Transmissive sensor
◼ Head open sensor
Real time clock
Standard
Internal font
◼ 8 alpha-numeric bitmap fonts
◼ Monotype Imaging® true type font engine with one CG Triumvirate Bold Condensed scalable
font
Bar code
◼ 1D bar code:
Code128UCC, Code128 subsets A
、
B
、
C, EAN128, Interleaved 2 of 5, Interleaved 2 of 5 with
