TSC PRINTRONIX ML240P User Manual

26
Wrinkles hppens from label lower left to upper right direction
 Switch the ribbon tension adjustment knob clockwise per 1 level and print the label again to check if the wrinkle is gone.
 If the tension adjustment knob has positioned on the level of outermost side but does not improve the ribbon wrinkle,
please switch the print head pressure adjustment knob per level and print the label again to check if the wrinkle is gone.
 If the wrinkle can’t be avoided, please contact the Customer Service Department of your purchased reseller or
distributor for service.
Feed Direction

TSC PRINTRONIX ML240P Specifications

General

Print Technology	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Speed	6 ips
Connectivity	Serial RS-232
Label Width	0.5 to 4.33 inches (12.7 to 110 mm)
Label Thickness	0.003 to 0.01 inches
Power Supply	100-240V AC, 50-60Hz
