TSC PRINTRONIX ML240P User Manual

33
 After clicking Set button, it'll pop-up the window tip
as below shown.
 IP address will be shown in the “IP address” field
and the Wi-Fi logo and IP address will be displayed
on the LCD control panel.
Note:
IP address should be shown within about 5~15
seconds after printer turn on. If not, please refer to
steps below to initialize the printer Wi-Fi module
settings then to setup it again.
 Remove the cable between the computer and the
printer.
 Go to main page, click Add Printer to add the
printer via Network.
 Select the printer and enter the setting page by
double clicking the printer.
 Click the Print Test Page button to print the test
page via Wi-Fi interface.

TSC PRINTRONIX ML240P Specifications

General

Print Technology	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Speed	6 ips
Connectivity	Serial RS-232
Label Width	0.5 to 4.33 inches (12.7 to 110 mm)
Label Thickness	0.003 to 0.01 inches
Power Supply	100-240V AC, 50-60Hz
