TSC TDP-225

TDP-225 Series
Bar Code Printer Service Manual
14
7. Take off the interface plate from the lower cover.
8. Reassemble the PCB, lower cover and lower front cover in reverse procedures.
9. Insert the under side of interface plate first then push the upper side of interface
plate to replace it.
Interface plate
PUSH
