TSC TTP-244 Plus User Manual

3. SET UP
3.1 Setting Up the Printer
1. Place the printer on a flat, secure surface.
2. Make sure the POWER switch is off.
3. Connect the printer to the computer mainframe with the RS-232C or USB
cable.
4. Plug the power cord into the power jacket at the rear of the printer, and then
plug the power cord into a properly grounded receptacle.
3.2 Loading Label and Tag Stock
1. Open the printer cover
2. Disengage the printer carriage by pulling the printer carriage release lever on
the left side of the platen.
3. Slide the label supply roll spindle through the core of a label roll and attach the
fixing tabs onto the spindle.
9

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
