TSC TTP-244 Plus - Page 13

3
2
1
2
4
1. Label Supply Roll Spindle
2. Label Roll Mount
3. Label Roll
4. Fixing Tabs
3
2
1
4
1. Printer Carriage Release Lever
2. Platen
3. Label Media
4. Adjustable Label Guide
