TSC TTP 246M - Loading Label For Peel-off Mode

16
3.6 Loading Label For Peel-off Mode
1. Open the Print Head Lift Lever. The message “CARRIAGE OPEN” will be
shown on the LCD screen, and the RED LED is on. The LCD panel shown
as below.
2. Remove the first one label from the liner. Insert the liner into the gap
Print Head Lift
Lever
ERRORON-LINE
MENU
CARRIAGE OPEN
Fwd. Rev.
POWER
PAUSE
FEED
SELECT
POWER
EXE./INC.
DEC.
