TSC TTP-268M User Manual

5
1.6 Media Specifications
Media Specifications
200 dpi models
300 dpi models
Label roll capacity
208.3 mm (8.2”)
Media alignment
Edge alignment
Media type
Continuous, die-cut, black mark, fan-fold, notch
Media wound type
Printing face outside wound
Media width (label + liner)
Max. 172.7 mm (6.8”)
Min. 50.8 mm (2.0”)
Media thickness (label +
liner)
Max. 0.254 mm (10 mil)
Min. 0.06 mm (2.36 mil)
Media core diameter
76.2 mm (3”)
Label length
Min. 10 mm (0.39”)
Label length (peeler
mode)
Max. 152.4 mm (6”)
Min. 25.4 mm (1”)
Label length (cutter
mode)
Max. 5,080 mm (200”)
Max. 2,540 mm (100”)
Min. 25.4 mm (1”)
Min. 25.4 mm (1”)
Gap height
Min. 2 mm
Black mark height
Min. 2 mm
Black mark width
Min. 8 mm (0.31”)
