1. Lift the handle to open the printer right side cover.
2. Push the print head release lever to open the print head mechanism.
3. Insert the fan-fold media through the rear external label entrance chute.
4. Pull fan-fold label leading edge forward through the media guide bar, damper,
media sensor and place the label leading edge onto the platen roller.
5. Adjust the label guide by sliding to fit the paper width.
6. Close the print head mechanism making sure the latches are engaged securely.
7. Set the media sensor type and calibrate the selected sensor. (Please refer to
section 3.1.2)
Note:
Please calibrate the gap/black mark sensor when changing media.
