2.8 Using the Keyboard with PS/2 Interface
1. Turn off the power of printer.
2. Plug the keyboard with PS/2 interface cable into PS/2 connector on the rear of the
printer.
3. Turn on the printer power switch.
4. Press keyboard F1 key, the following options will display on the LCD.
5. Use up ↑ or down ↓ key to move “>” cursor on the memory type and press
Enter key to list files on the LCD display.
6. Select the file and press Enter key to execute the .BAS file.
7. Then, you can type the data from keyboard for stand-alone application.
Here below are the summary of the keyboard operation.
Press F1 key of the keyboard to start this function.
Press up ↑ or down ↓ key of the keyboard to move cursor of printer LCD display to select
the option.
Press Esc key of the keyboard to return the previous menu.
Press Enter key of the keyboard to enter/execute cursor located option.
Press Ctrl + C keys of the keyboard to restart the printer and back to “Ready” state.
