TSC TTP-268M User Manual

4
1.3 General Specifications
General Specifications
Physical dimensions
355 mm (W) x 337 mm (H) x 510 mm (D)
Weight
23 kg (48.5 lb)
Electrical
Internal switching power supply
Input: 90~230VAC, 47~63HZ
Output: 24V, 14.58A, 350W
Environmental
condition
Operation: 5 ~ 40˚C (41 ~ 104˚F), 25~85%
non-condensing
Storage: -40 ~ 60 ˚C (-40 ~ 140˚F), 10~90%
non-condensing
1.4 Print Specifications
Print Specifications
200 dpi models
300 dpi models
Print head resolution
203 dots/inch (8 dots/mm)
300 dots/inch (12 dots/mm)
Printing method
Thermal transfer and direct thermal
Dot size
(width x length)
0.125 x 0.125 mm
(1 mm = 8 dots)
0.084 x 0.084 mm
(1 mm = 12 dots)
Print speed
(inches per second)
4, 5, 6, 7, 8 ips selectable
Up to 8 ips
4, 5, 6 ips selectable
Up to 6 ips
Max. print width
168 mm (6.61”)
Max. print length
14,732 mm (580”)
6,604 mm (260”)
Printout bias
Vertical: 1 mm max.
Horizontal: 1 mm max.
1.5 Ribbon Specifications
Ribbon Specifications
Ribbon outside diameter
Max. 81 mm
Ribbon length
450 meter
Ribbon core inside
diameter
1 inch (25.4 mm)
Ribbon width
Max. 178 mm (7”)
Min. 50.8 mm (2.0”)
Ribbon wound type
Ink coated outside wound, ink coated inside wound
Ribbon end type
Transparency
