TSC TTP-268M User Manual

21
2.6.3 Loading Media in Peel-off Mode (Option)
1. Install the label. (Please refer to chapter 2.6.1)
2. Using the front display panel to set the media sensor type and calibrate the
selected sensor. (Please refer to chapter 3.1.2)
3. Install the paper core to internal rewind spindle.
4. Pull approximately 650mm of label through the front of the printer and take some
labels off only leave the liner.
5. Feed the liner into peel-off cover slot.
Internal rewind
spindle
Paper core
Slot
