3. Open the print head mechanism, put the black
mark under the media sensor. Press the
button to set the value into the
printer.
4. Then, put the label without black mark under
the media sensor. Press the
button to set the value into the printer.
Note:
Normally, the value of “Ref. Level” for mark should be larger than paper for over
128. If the media sensor fails to do so, you have to manually change the
Intensity by pressing and to reach the above value.
5. The bline sensor calibration is complete.
Press the button the LCD screen
will return to the previous menu.
B-3 Pre-Printed
This function will need to set the paper length and gap size before
auto-calibrate the sensor sensitivity. It can get the sensor sensitivity more
accurately for pre-printed media.
To Next Page
