B. Bline Mode
28
Press the and buttons to scroll the cursor to the sensor type. Press
the button to enter the black-mark sensor calibration mode.
B-1 Automatic
When enter the [Automatic] option, you will see following message and
printer will feed the black-mark label to calibrate the sensor sensitivity
automatically. When calibration process is completed, the LCD screen will
return to the previous menu.
B-2 Manual
In case “Automatic” sensor calibration cannot apply to the media, please
use “Manual” function to calibrate the bline sensor manually.
When enter [Manual] option, you will see following message. Please
complete there steps：
Paper Len.
00151 dot
1. Press the button to move
the cursor from left digit to right digit,
and press the
button to set
the value from “0” to “9” and the “dot/
mm/ inch”. Press the
button to set the paper length into the
printer.
Bline Size
0024 dot
2. Press the button to move
the cursor from left digit to right digit,
and press the
button to set
the value from “0” to “9” and the “dot/
mm/ inch”. Press the
button to set the bline size into the
printer.
Calibration 2/4
Gap Mode
> Bline Mode
Cont. Mode
Bline Mode 1/4
> Automatic
Manual
Pre-Printed
Bline Mode
Automatic
Bline Mode 2/4
Automatic
> Manual
Pre-Printed
