3.3 Diagnostics
Diagnostics
ExitPrint Config. Dump Mode Rotate Cutter
3.3.1 Print Config.
This feature is used to print current printer configuration to the label. On the
sconfiguration printout, there is a printhead test pattern, which is useful for checking if
there is any dot damage on the printhead heater element.
Diagnostics 1/4 Self Test ... Printing ...
> Print Config. 1/1
Dump Mode
Rotate Cutter
Self-test printout
Printhead check pattern
Model name and F/W version
Printed mileage (meter)
Firmware checksum
Serial port configuration
Code page
Country code
Print speed (inch/sec)
Print darkness
Label size (inch)
Gap distance (inch)
Gap/black-mark sensor sensitivity
Numbers of download files
Total & available memory space
40
