3-4 Electrostatic Classifier Model 3082 and SMPS Spectrometer Model 3938
a. Remove neutralizer (see previous steps).
b. Tilt and lift the cover leaving the five loosened screws in place.
c. Remove four (4) screws holding the neutralizer enclosure in place.
Rest on top of the classifier.
d. Locate the lead shielding and carefully lift out.
e. Replace the flag assembly housing.
f. Replace the instrument cover.
