TSN Systems Box 3.0 - Host Side Connectors

TSN Box Development – TSN Box 3.0 Getting Started Guide
Hardware – 7
7 1000BASE-T1 – Port 8
8 100BASE-T1 – Port 1
9 100BASE-T1 – Port 2
10 100BASE-T1 – Port 3
11 100BASE-T1 – Port 4
12 SMA In 1
13 SMA In 2
14 SMA Out 1
15 SMA Out 2
16 Reset Button
17 Recovery Button
2.4.2 Host Side Connectors
