1 Introduction
This is the manual for the TSN Box Version 3.0, onward referred to as the unit. The document describes the
hardware and software of the TSN Box.
2 Hardware
2.1 General Description
The unitis a high-performance analysis tool for time sensitive networks providing the following features:
• Host Intel® Celeron-series System-on-Chip (SoC)
• Intel® Celeron
TM
N2930, DC, 1.83/2.16GHz, 2MB L2 Cache
• 8 GB DDR3 Memory
• 2x USB2.0 Ports
• 1x USB3.0 Port
• 1x 1Gb Ethernet Port
• 1x USB Serial Terminal Port
• 2x Isolated Input
• 2x Isolated Outputs (open-collector)
• 1x Output Power (non-isolated)
• 12x Audio Ports (6 x stereo connectors)
• 8x Outputs channels
• 4x Input channels
• 2x High-speed GPI (SMA, 50Ω load impedance)
• 2x High-speed GPO (SMA, 50Ω source impedance)
• Front Panel Reset
• Front Panel General Purpose Button
• 2x Dual 1Gb Modules
• Configured as either 2 x 1000BASE-T or 2 x 1000BASE-T1 or none
• 1x Quad 100Mb Module
• Configured as either 4 x 100BASE-T1 or 4 x 100BASE-TX or none
• 1x SYNC Module
• Configured as 2x PPS/SYNC Ports (50Ω) or none
• 1x CAN Module
• Configured as 1x CAN Channel or none
2.2 Technical Description
The unit consists of a base board with multiple module slots that can be configured in different options and
expanded on in future releases. There are 6 module slots in total.
Audio Slot
The Audio Module can be configured with 8 output channels and 4 input channels over 6 stereo 3.5mm connectors.
There are two audio codecs on the Audio Module, one controlled by the FPGA and one controlled by the Host CPU
as an HDA audio device. The input channels share the same connectors and the output channels are multiplexed
and controlled by the FPGA.
Dual 1Gb Slot #1
