Tunaylar Load Line 2 - Page 26

P5.4
P5.6
Ports for
Address
Manual Data
Transmit
2
Select port names for manually transmitting
data(data protocol is given in sections).
later
Alibi memory reports can be taken through
this parts.
Slave Ports
RS 422 / 485
0
0
0
Disable
(---)
Disable
Disable
1
1
1
Com 1
Com 1
Com 2
2
2
2
Com 2
Com 2
Com 3
3
3
3
4
4
5
5
6
6
7
7
Com 3
Com 3
Com 2 + Com 3
Com 1+2
Com 1+2
Com 1 + 3
Com 1 + 3
Com 2 + 3
Com 2 + 3
Com 1 + 2 + 3
Com 1 + 2 + 3
Device can be used as slave or master. Select
port names which will be used as slave ports.
Select port names for RS422/485 data
communication. These ports are full duplex.
25 KM.LL2E.002
1
001
0
SYMBOL NAME ALTERNATIVES DEF. EXPLANATION
P5.5
P5.7
Max. of 32. indicators can be connected.
Enter. device's address information here.
If this value is left as zero then the slave
port will not work properly.
