P6.1 Output
Assign
-------
Press Enter button to go next one. You dont
have to enter all of 4 outputs, you can exit at
any time by using Esc button.
Example: if output 1 is assigned to inputs 1
and 3, select output 1 (Out 1) and press
enter button. Then write
the result of
following formula:
1x1 + 0x2 + 1x4 + 0x8 = 06
P6.2
Output
Set Point
Weights
-------
You can define 4 different set point weights.
Enter set weight value s by using numerical
buttons and then
press Enter button to go
next one. You dont have to enter all of 4 set
values, you can exit at any time by using Esc
button.
Example: if displayed weight value (brut or
net) is smaller than set point 1, output 1 will
be open till it exceeds set point 1.
As soon as
weight value is greater than or equal to set
point 1, output 1 is closed.
P6.3
Input
Operating
Type
0 Disable
1 Standard
2 External
Buttons
0
You can select operating type of the set point
inputs.
If 0 (disable) is selected, inputs will be
disabled.
If 1 (standard) is selected, inputs will be
enabled.
If 3 (external buttons) is selected, 1
st
in put
will be used as tare button, 2
nd
input will be
used as zero button and 3
rd
input will be used
as print button.
P6.4
Application
Type
0 Filling
1 Level
Measuring
If 0 is selected , outputs will not be set while
weight is returning back to zero un til zero is
displayed. If 1 is selected , outputs will be set
as soon as weight is smaller than related set
point value.
27
KM.LL2E.002
