Tunstall ConnectCall - Access Control Management

Access Control
The system may be equipped with the Tunstall fob access system. This allows users who are issued
with a fob to gain access through certain doors that are equipped with a reader.
The reader is normally mounted within the door panel or next to a warden call panel.
The fob that is used to gain access is a device that does not require any maintenance or batteries.
Adding a fob
All fobs that are added to the system are assigned via the SCP. If the SCP shows Press * to unlock.
Press the * key to unlock the SCP followed by the menu key or select Menu, using the keys next to the
display if the SCP is unlocked.
23:59
01/07/2007
Menu On Site
Figure A.16
Select ‘Access ctl’ from the menu
Call Menu
Trigger Menu
Settings >
Access Ctl Exit
Figure A.17
Now select Add Device.
Add Device
Delete Device
Settings
Exit
Figure A.18
The following menu has four stages that need to be completed, first start by selecting ID from the
menu.
