V04.00 | 2021/05
111
Bit Name Definition
4…7 Extended Device Status 0011 = no I/O connection established
0110 = at least one I/O connection in RUN
mode
0111 = at least one I/O connection established,
all in IDLE mode
All other settings = reserved
8 Minor recoverable fault Recoverable fault, e.g.:
n Undervoltage
n Force-Mode in DTM active
n Diagnostic active at I/O channel
9…10 reserved
11 Diag Common error bit
12…15 reserved default = 0
Common services
Service code Class Instance Service name
Dec. Hex.
1 0x01 Yes Yes Get_Attribute_All
returns a predefined list of object attributes
5 0x05 No Yes reset
starts the reset service for the device
14 0x0E Yes Yes Get_Attribute_Single
returns the content of a specified attribute
16 0x10 No No Set_Attribute_Single
changes a single attribute
Assembly Object (0x04)
Assembly Objects bind attributes of multiple objects. to allow data to or from each object to be
sent or received over a single connection.
The following description of the Ethernet Link Object is taken from the CIP specification, Vol. 2,
Rev. 2.1 by ODVA & ControlNet International Ltd. and adapted to the Turck products.
Class attributes
Attr. no. Attribute name Get/set Type Value
Dec. Hex.
1 0x01 Revision G UINT 2
2 0x02 Max. object instance G UINT 104
Instance Attributes
Attr. no. Attribute name Get/set Type Value
Dec. Hex.
3 0x03 Data S ARRAY OF
BYTE
Identifies a special product
in a device type.
default: 27247dec = 6A6F
4 0x04 Size G UINT Number of bytes in attrib-
ute 3:
256 or variable
