turck TBEN-S2 - Process Output Data - Analog Modules

Parameterizing and Configuring
Process output data – overview
56
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Name Meaning
CNT reset Counter reset bit
Sets the counter value back to 0 and starts a new count operation.
P1 Pin 1
Duty Cycle Mark-to-space ratio 10 %…90 %
VAUX1 P1 C1 Switches the sensor/actuator supply at pin 1 of the connector.
8.3.2 Process output data – analog modules
TBEN-S2-4AO
Word no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Control
0x0000 - - - - - - - - - - - - - - - -
Outputs
0x0001 Analog value channel 0
0x0002 Analog value channel 1
0x0003 Analog value channel 2
0x0004 Analog value channel 3
