Technical Data
Technical data TBEN-S1-4DXP
230
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
14.7 Technical data TBEN-S1-4DXP
The device has four DXP channels. Up to four 3-wire PNP sensors or four PNP DC actuators can
be connected.
Technical data
Supply
Operating current (from V1) < 150 mA
Sensor/actuator supply VAUX1 Supply connector C0…C1 from V1
short-circuit proof, 0.5 A per port
Sensor/actuator supply VAUX2 Supply connector C2…C3 from V2
short-circuit proof, 0.5 A per port
Potential isolation From V1 and V2 voltage group,
voltages up to 500 VDC
Total current Total current max. 4 A per voltage group
Total current V1 + V2 max. 5.5 A at 70°C per
module
Digital inputs
Number of channels 4
Connection technology M8, 3-pole
Input type EN 61131-2 type 3, PNP
Type of input diagnostics Group diagnostics
Signal voltage low level < 5 V
Signal voltage high level > 11 V
Signal current low level < 1.5 mA
Signal current high level > 2 mA
Input resistance low level Min. 3.33 kΩ
Input resistance high level Max. 5.5 kΩ
Input delay 0.2 ms/3 ms
Input frequency 400 Hz
Potential isolation Galvanic isolation to P1/P2,
voltage proof up to 500 VDC
Digital outputs
Number of channels 4
Connection technology M8, 3-pole
Output type PNP
Type of output diagnostics Channel diagnostics
Output voltage 24 VDC from potential group
Output current per channel 2 A, short-circuit-proof
Load type EN 60947-5-1: DC-13
Load type (UL condition) Resistive, pilot duty
Short-circuit protection Yes
Potential isolation Galvanic isolation to P1/P2,
voltage proof up to 500 VDC
General information
MTTF 307 years acc. to SN 29500 (Ed. 99) 20 °C
