Technical Data
Technical data – TBEN-S2-4AO
238
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
14.11 Technical data – TBEN-S2-4AO
The module provides four analog current or voltage outputs.
Technical data
Power supply
Operating current V1: min. 50 mA, max. 110 mA
V2: min. 30 mA, max. 70 mA
Sensor/actuator supply VAUX2 Supply connector C0…C3 from V2
short-circuit proof, 4 A per group C0…C3
Potential isolation V1/V2/Ethernet Galvanic isolation from V1 and V2 voltage
group, voltages up to 500 VDC
Power loss of the device, typical 3 W
Analog outputs
Number of channels 4
Operating Modes n Voltage
n Current
Load type (UL condition) Resistive, pilot duty
Resolution 16 bit
Operation mode voltage
Voltage ranges -10…10 V, 0…10 V, 2…10 V, 0…5 V, 1…5 V
Output signal Single ended
Load resistance > 1 kΩ
Cycle time ≤ 4 ms
Basic error at 25 °C 0.1 %
Repeatability ± 0,05 % at 25 °C
Temperature coefficient < 20 ppm/°C of full scale
Measurement error total (FSR) < 0,23 %
Operation mode current
Current ranges 0…20 mA, 4…20 mA
Burden resistance < 600 Ω
Cycle time ≤ 4 ms
Basic error 0.15 %
Repeatability ± 0,05 % at 25 °C
Temperature coefficient < 20 ppm/°C of full scale
Measurement error total (FSR) < 0,28 %
No-load voltage Typ. 24,5 V
Crosstalk (channel to channel) > -60 dB
Data format n Standard 16 bit/12 bit left justified
n NE43
n Extended range
Output ripple Max. 0.02 %
Isolation voltage V1/ V2/Ethernet Min. 500 V
General information
MTTF 244 years acc. to SN 29500 (Ed. 99) 20 °C
